Caddy 14d disc Brake Caliper Adapter G60 caliper Rear Lowering
- ✓ 226x10 357615601 G60 brake disc
- ✓ 1-piston Girling 38 191615423 / 191615424 brake caliper
- ✓ rear axle
€135.21*
- Easy TÜV registration
- Quality Made in Germany
- Fair prices without middlemen you buy directly from the manufacturer and developer of the product
- Worldwide no. 1 in tuning adapters
- 15 years expert knowledge
- 10 years warranty
Rear axle adapter kit to convert the Caddy 14D rear axle to G60 disc brake.
Advantages:
- ability to brake and vent a lot better than a conventional drum brake
- top otics and profesionnal conversion
- lowered rear axle by 25mm
- thanks to the material certificate supplied with the order and to a correct conversion, it is possible to register your purchase even for series vehicles
- can always be restored to the original state without any problems
With our brake caliper adapters, the G60 brake discs and brake calipers can be installed onto the Caddy 14d. With our adapter, the track is 15mm wider per side and the vehicle ist 25mm deeper on the rear axle.
You only need the G60 axle stubs of the rear axle.
Delivery:
- 2x brake caliper adapters (high-strength steel)
- high-strength mounting screws (10.9)
- material certificate
- Installation instructions
With this conversion kit, the S3 / R32 brake can be installed in conjunction with our spacer adapter, combined with the 280mm brake discs on the rear axle.
In our shop, we also have corresponding adapters for the front axle to convert to the G60 280 brake. Visit our shop!
Tips, information and hints:
- For a better ventilation of the brake system, we recommend removing the dust cover plates and brake anchor plates.
- We can not answer generally, which rim size you can mount after your brake conversion. There are simply too many different rims.
- In rare cases it is possible that the rims touch minimal the brake caliper, then you can simply use spacers.
>> Now directly to spacers << - Install the adapter with the necessary components and then check if new brake lines are required. Because, depending on the vehicle, the lines may be too short or the line tips may not suitable. We advise you to change to steel braided brake line because of the quality and technical advantage. Specifically for this, we have developed an online brake line configurator, where you can assemble the type of steel braided brake lines you want.
Click here to go to the >> configure steel braided brake lines << - Always use the hand brake cable of the installed brake caliper. So sometimes you have to modify / adapt the new handbrake cable. For conversions, where the original caliper is used and the handbrake cable can be used, you may need to pull the cable without any other fittings (ie directly) to compensate for the long distance due to the large diameter of the large brake discs.
Please note that our articles have been designed for racing and motorsport. Use in public road traffic usually requires an individual approval in accordance with § 21 StVZO by an officially recognised expert. Further information can be found under TÜV Süd. For the individual approval, we will provide you with an expert opinion or material certificate, if available.
Technical data:
Login
27 March 2020 07:40
Kai B
Guten Tag, ich bin absolut zufrieden mit dem Ergebnis. Und der hochwertigen Qualität und Verarbeitung der Platten, ich habe und werde jedem weiterempfehlen bei Ihnen mal vorbei zu schauen, und sich selbst von der sehr großen Produktpalette zu Überzeugen.
9 September 2018 20:55
Josh H
Diese Konversionsplatten sind von hervorragender Qualität und werden auf einem sehr hohen Standard hergestellt. Die Passform ist auch perfekt, ich würde jedem empfehlen! Entschuldigung für die Fehler in meinem Deutsch im Versuch, aus dem Englischen zu übersetzen
23 January 2019 14:47
Christian R
Super Sache!
13 March 2020 08:19
Kai B
Ich bin mit der Qualität der Passgenauigkeit und dem Endergebnis wirklich sehr zu Frieden und werde sie stets weiter empfehlen u d auch weiterhin bei Bedarf bei Ihnen bestellen. Vielen lieben Dank für den tollen vorbildlichen Service so macht tuning spaß🤗
30 June 2022 19:52
Andy A
1A Adapter für mein Umbau von Trommel zur Scheibenbremse hat alles super gepasst für mein Caddy 14d. und sehr guter Kontakt . Gruß Andy.
8 May 2019 11:42
Constantin K
Das Produkt ist super und erfüllt ihren Zweck. Leider keine Einbauanleitung mit Drehmomenten und bei der Beratung, welches Teil ich benötige, ist auch etwas schief gelaufen sodass ich mehr zahlen musste als eigentlich nötig gewesen wäre.
- Can I also use other brake discs as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information: https://epytec.de/uk/custom-made-products/brake-technology/adapters-for-brake-systems
- Can I also use other brake calipers as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information:
