Brake caliper adapter for the front axle of the Alfa 155 Q5 to the 305x28mm Fiat Abarth brake disc in conjunction with the Porsche 997 4-piston brake calipers

Alfa Romeo 155 Q4 brake upgrade to 305x28mm Fiat Abarth brake disc in combination with Porsche 997 calipers ( 129090 )

The customer's request / problem:

Our customer Jens would like to install the following brake system on the front axle of his Alfa Romeo 155 Q4

305x28mm Brake disc from Fiat Abarth part no: 51885455
4-piston calipers from 997 Porsche part no: 997.351.421 / 422

If you would like to have your brake system measured by us, please send us your components to the following address:

!!Important!! Please enclose a note with your contact details so that we can get back to you with the quotation!!!

Epytec GmbH
Neuhäuser 10
79244 Münstertal
Germany

Our realisation / solution:

Sent the following components

Jens sent us the following components to adapt the brake system on the front axle:
305x28mm brake disc from Fiat Abarth part no: 51885455
4-piston calipers from 997 Porsche part no: 997.351.421 / 422

Measurement:

After we have received the components from Jens, we check directly whether the complete system is realisable and whether an adaptation is possible.

To do this, we plug the brake system together.

You can clearly see that the complete system is possible.

Here are a few more pictures of the measurement.

CAD-Processing

After Jens us his "okay" for the offer. Can we precisely machine the brake caliper adapter for the Alfa Romeo 155 Q4 on the Porsche 977 brake system with the 308x25mm Abarth brake discs in our CAD program.

3-D Prototyping

The final prototype is tested directly in our workshop to see whether it is also compatible with the brake system for the Alfa Romeo 155 Q4.

We always work with a 3D model in advance, as it often happens that certain dimensions and conditions cannot be taken into account in advance on the tuning adapter. With the 3D test model, we can check exactly whether everything has been measured correctly. For example, it is checked whether the brake disc runs centrally and the brake pad is not over.

Production of the brake caliper tuning adapter

After everything fits and could be checked with the 3D test model, we can finally manufacture your brake caliper tuning adapter for the 4-piston Porsche brake system in connection with the Fiat Abarth 305x28mm brake discs.

After the brake tuning adapter from the surface refiner has arrived back at us and was sent directly to Jens. He has everything mounted and sent us super installation pictures of his new brake Tuning adapter - Thanks for that!

Installation pictures from Jens

Here you can see more pictures of the Alfa Romeo 155 Q4 tuning conversion to the 4-piston Porsche 997 brake calipers (997.351.421 / 422) in combination with the 305x28mm brake disc from fiat Abrath (51885455)

If you would like us to measure your brake system as well, please send us your components to the following address:

!!Important!! Please include a note with your contact details so that we can contact you with the offer! !!

Epytec GmbH
Neuhäuser 10
79244 Münstertal
Germany

We will also help you with your individual solution

If, like Matthias, you want have a tuning conversion of your brake system according to your wishes, then simply get in touch with us using our contact form and we will also help you to make your conversion dream come true. With more than 15 years of experience in the production of tuning parts, we can realise your conversion quickly and cost-effectively. We look forward to your inquiry!

Would you like to have the same brake combination for the Alfa Romeo 155 Q4? Then please send us a message via our contact form with the reference (129090) and we will send you an offer for your custom-made product.
