Brake Caliper Adapter BMW 5 Series F06 F10 F11 6 Series F06 F12 F13 BMW 840i 4-Piston Brake Calipers 374x36mm Brake Discs

Name: Brake Caliper Adapter BMW 5 Series F06 F10 F11 6 Series F06 F12 F13 BMW 840i 4-Piston Brake Calipers 374x36mm Brake Discs
Brand: EPYTEC
SKU: 1317
Price: 47.5 EUR
Availability: InStock

€47.50*

Prices incl. VAT plus shipping costs

Available

Product number: 1317

Delivery by Wednesday, 17.12.2025 if you order within the next 7 Hours.

Only 4 left in stock!

Product number: 1317

Brake caliper hole spacing: 138

Hole spacing steering knuckle: 138

Manufacturer: Epytec

Mounting location: front

Brake calliper adapter for the front axle of the BMW 5 and 6 Series (F06, F10, F11, F12, F13) to BMW 840i 4-piston brake system

This brake calliper adapter enables the front axle of the BMW 650i xDrive (F06) to be professionally converted to the powerful 4-piston brake system of the BMW 840i xDrive. In conjunction with the large 374x36 mm Brembo brake discs from the BMW 550i, the result is a significantly improved brake system with a sporty look and enhanced performance. Ideal for drivers who want to retrofit a large brake as part of a high-quality tuning programme.

Adapters are suitable for the following BMW with the part number: Wheel bearing housing number: 31216775770 / 31-21-6-775-770

BMW 6er Gran Coupé F06
BMW 5er F10 F11
BMW 6er F12 F13

Advantages of this brake system:

Our components, such as brake callipers and brake discs, come from standard vehicles and are OE parts. This makes replacing the brakes simple and straightforward and facilitates registration with the TÜV.

Significantly improved deceleration values thanks to 4-piston brake callipers from the BMW 840i
Large 374x36 mm Brembo brake discs ensure better heat dissipation
No adjustments to the vehicle necessary - plug & play solution
Can be retrofitted at any time - ideal for temporary tuning
Epytec quality: precise fit and easy installation without welding or milling work
Material certificate is included

Required components

Brake caliper:
- BMW 4-piston brke caliper from 840i xDrive G15
- part number: 34116891303, 34116891304

Brake discs:
- 374x36mm from BMW 550i F10 F11
- part number: 09.C417.13

Brke pads:
- part number: P06106

Scope of delivery

2x brake calliper adapter for BMW 5 Series F06, F10, F11, F12, F13
High-strength screw material
Material certificate for individual approval

Optimised brake tuning with Epytec

This high-quality brake upgrade gives your BMW 5 Series 6 Series noticeably better brakes and ensures increased driving safety and performance. Thanks to the use of OE components such as BMW 840i brake callipers and Brembo discs from the 550i, the conversion is particularly reliable and TÜV-friendly. Installation is simple, fully reversible and perfectly suited for anyone who favours a large brake when tuning. Epytec supplies the right solution for your tuning project.

FAQ: Häufig gestellte FragenrnSollte ich die Ankerplatten bzw. Staubschutzbleche entfernen?rnWir empfehlen, die Metallbleche zu entfernen, da sie die Belüftung einschränken. Ohne diese Barriere wird die Bremse effizienter gekühlt und bleibt selbst bei starker Beanspruchung leistungsfähig.rnWie kann ich die Montage der Felgen erleichtern?rnMontagehilfen für Räder erleichtern und präzisieren das Ausrichten und Aufsetzen der Felge. Dies schützt das Gewinde und die Felge und spart Zeit.rnMontagehilfe für Räder ansehenrnBenötige ich Spurplatten nach dem Umbau?rnEs gibt keine allgemeine Regel zur Bestimmung der passenden Felgengröße. Wenn die Felge leicht am Bremssattel schleift, können Spurplatten verwendet werden, um den notwendigen Abstand zu schaffen.rnSpurplatten ansehenrnBenötige ich neue Bremsleitungen?rnFür eine optimale Passform und eine stabile Bremsleistung empfehlen wir Stahlflexleitungen. Diese sind konfigurierbar und liefern konstantere Ergebnisse als Gummileitungen.rnStahlflex konfigurierenrnWarum unsere Adapter die beste Wahl sindrnWussten Sie, dass sich Ihr EPYTEC Adapter oft bereits nach dem ersten Austausch von Verschleißteilen bezahlt macht?rnDies liegt daran, dass unsere Adapter für OE-Bremsscheiben und Bremssättel ausgelegt sind, die wir bei der Entwicklung bewusst ausgewählt haben. Diese Komponenten werden nicht nur in höchster Qualität gefertigt und in Serienfahrzeugen eingesetzt, sondern sind aufgrund ihrer Großserienproduktion auch günstig und leicht verfügbar.rnFür Sie bedeutet das eine erstklassige Bremsleistung, ohne auf teure Speziallösungen anderer Hersteller angewiesen zu sein.rnUnd selbst bei der HU (TÜV) haben Sie es leichter, denn unsere OE-Komponenten sind bereits offiziell zugelassen – der Prüfer kann direkt darauf verweisen, sodass Ihre Eintragung unkompliziert und sicher ist.

Please note that our articles have been designed for racing and motorsport. Use in public road traffic usually requires an individual approval in accordance with § 21 StVZO by an officially recognised expert. Further information can be found under TÜV Süd. For the individual approval, we will provide you with an expert opinion or material certificate, if available.

We provide a material certificate for this adapter, allowing the TÜV inspector to easily register the adapter.

Brake caliper hole spacing: 138

Hole spacing steering knuckle: 138

Manufacturer: Epytec

Mounting location: front

Brake caliper hole spacing: 138

Hole spacing steering knuckle: 138

Manufacturer: Epytec

Mounting location: front

0 of 0 reviews

Leave a review!

Share your experiences with other customers.

Login

email address

password

or Register with...

No reviews found. Share your insights with others.

Can I also use other brake discs as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information: https://epytec.de/uk/custom-made-products/brake-technology/adapters-for-brake-systems
Can I also use other brake calipers as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information:
