BMW E46 M3 Brake Caliper Adapter Porsche 996 E46 M3 CSL 345x28 Brake Disc

  • ✓ 345x28 34112282445 BMW E46 M3 CSL brake disc
  • ✓ 4-piston 996351425 / 996351426 Porsche 996 brake caliper
  • ✓ front axle

Brake caliper adapter , front axle, on models BMW E46 M3  for conveersion to the large BMW E46 M3 CSL brake discs, 345x28 mm, combined with brake caliper from Porsche 996.

Suitable for all M3 E46 models, without modifications. This brake system can also be fitted to all other E46 models. Only important is the conversion on axle pin / stub  or wheel hub from M3 E46.

Advantages of this brake system:

  • high deceleration
  • thanks to the material certificate supplied with the order, it is possible to register your purchase even for series vehicles
  • directly fit to the above-mentioned models and therefore can always be restored to the original state without any problems
  • Our EPYTEC brake caliper adapters do not require any sending of your serial parts, no welding, milling or drilling

Required components:

  • brake caliper: Porsche 996, reference 996.351.425 + 996.351.426
  • brake disc: BMW E46 M3 CSL  345x28mm (front axle) , reference 34 11 2 282 445
  • The brake caliper must be milled off approx. 5.5mm on the contact surface.

Rinms: at least 19 inch.

Delivery:

  • 2x brake caliper adapters for BMW E46 M3
  • high-strength mounting screws
  • material certificate

Tips, information and hints:

  • For a better ventilation of the brake system, we recommend removing the dust cover plates and brake anchor plates.
  • We can generally not answer, which rim size you can mount after your brake conversion. There are simply too many different rims.
  • In rare cases it is possible that the rims touch minimal the brake caliper, then you can simply use spacers. >> Now directly to spacers <<
  • Install the adapter with the necessary components and then check if new brake lines are required. Because, depending on the vehicle, the lines may be too short or the line tips may not suitable. We advise you to change to steel braided brake line because of the quality and technical advantage. Specifically for this, we have developed an online brake line configurator, where you can assemble the type of steel braided brake lines you want. Click here to go to the configurator >> Configure steel braided brake lines <<

Please note that our articles have been designed for racing and motorsport. Use in public road traffic usually requires an individual approval in accordance with § 21 StVZO by an officially recognised expert. Further information can be found under TÜV Süd. For the individual approval, we will provide you with an expert opinion or material certificate, if available.

Technical data:

Einbauort: vorne
Lochabstand Achsschenkel: 122mm
Lochabstand Bremssattel : 130mm
Einbauort: vorne
Lochabstand Achsschenkel: 122mm
Lochabstand Bremssattel : 130mm

9 of 9 reviews

Average rating of 4.7 out of 5 stars


78%

22%

0%

0%

0%


Leave a review!

Share your experiences with other customers.


17 June 2021 15:57

Review with rating of 5 out of 5 stars

Dragan R

Es wurde ein Porsche Bremssattel auf einen BMW M3 E46 Competition verbaut. Super Verarbeitung und sehr hochwertig. Jeder der umbauten an den Bremsen macht ist hier gut aufgehoben und beraten. Top Ergebnis und eine tolle Optik und alles mit Material Zertifikat (TÜV-Konform)

13 September 2020 11:46

Review with rating of 5 out of 5 stars

Necdet T

Super ware passt 100% Dankeschön

13 September 2020 12:33

Review with rating of 5 out of 5 stars

Necdet T

Super ware passt 100% . Dankeschön

15 September 2020 09:20

Review with rating of 5 out of 5 stars

Necdet T

Super ware passt 100% . Dankeschön

23 November 2019 08:36

Review with rating of 5 out of 5 stars

Patrick M

Qualität und Preis stimmen, alles was zum Verbau benötigt wird ist dabei, alles bestens

15 September 2020 13:41

Review with rating of 5 out of 5 stars

Necdet T

Super ware passt 100% . Dankeschön

30 August 2020 09:29

Review with rating of 5 out of 5 stars

Necdet T

Super Passform:-)

24 December 2020 09:09

Review with rating of 4 out of 5 stars

Lucas J

Très bon produit. Vis de fixation étrier 4mm trop longue le mieux serait des tige filetée qui soit fixe dans l'adaptateur. Il faut un peux limé la fixation sur la jambe de force, petite découpe en bas de la tôle par chaleur pour le passage de l'étrier. Il manque tous les couple de serrage pour les vis ça serait bien de les avoir. Usinage de 5.5mm obligatoire sur la surface de fixation de l'étrier pour que tout se monte parfaitement Produit bien fini et très compétitif niveau tarif.

16 June 2020 11:24

Review with rating of 4 out of 5 stars

Vinicius L

J'ai mis la note de 4 étoiles car j'ai dut faire quelques adaptations sur le kit pour pouvoir l'installer. Produit de tres bonne qualité. Je recommande à tous ceux qui veulent avoir du freins sur leur m3 e46. Epytec les vis de fixations de l'étrier sur la cale sont trop longues elle touche la fusée j'ai dut les raccourcir. Le montage est fait et impeccable reste plus qu'a roder les freins merci epytec.

  • Can I also use other brake discs as specified in the required components?
  • No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information: https://epytec.de/uk/custom-made-products/brake-technology/adapters-for-brake-systems

  • Can I also use other brake calipers as specified in the required components?
  • No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information:
