Brake calliper adapter BMW X1 X2 2 Series Mini Clubman 390x36mm brake disc Mercedes AMG brake calliper 6 pistons
€258.69*
Available
Product number:
1285
Delivery by Friday, 05.12.2025 if you order within the next 13 Hours.
Product number:
1285
Weight:
2.667 kg
Brake caliper hole spacing:
256
Hole spacing steering knuckle:
138
Manufacturer:
Epytec
Mounting location:
front
Brake calliper adapter for the front axle of the BMW X1 X2 2 Series Mini to Mercedes W204 AMG 6-piston brake callipers
The brake calliper adapters allow the front axle of the BMW X1 (F48 / F49), X2 (F39), 2 Series (F22 / F23 / F45 / F46) and Mini Clubmen (F54) to be converted to high-performance Mercedes W204 AMG 6-piston brake callipers in combination with large 390x36mm brake discs. This upgrade significantly improves braking performance and ensures sportier deceleration.
The adapters fit the following vehicles with this wheel bearing housing number: 687664501L, 6876854, 621654-10
- BMW X2 (F39)
- BMW X1 (F48 / F49)
- BMW 2er (F22 / F23 / F45 / F46)
- Mini Clubman (F54)
Advantages of this brake system:
- Significantly improved deceleration values thanks to the powerful AMG 6-piston brake callipers
- Optimum heat dissipation and reduced fading thanks to the large-format brake discs
- Direct installation on the above-mentioned models, can be retrofitted at any time
- No modifications to the vehicle necessary - plug & play solution
- EPYTEC brake caliper adapters do not require the return of standard parts, no rewelding, re-milling or re-drilling
Required components:
Mercedes W204 AMG 6-piston brake callipers
- Part number: A4634205100 / A4634205200
- Brembo number: 20.9553.01 / 20.9553.02
Brake pads
- A0074206520
Brke disc 390x36mm from Mercedes M-Class/ GLE / GLS Coupe / GL-Class
- Part number: 1664210512
Scope of delivery:
- 2x brake calliper adapter for BMW X2, X1, BMW 2 Series and Mini Clubman
- High-strength screw material
- Material certificate for registration via individual approval
This high-quality brake upgrade ensures optimised handling, greater safety and an improved appearance. Perfect for tuning enthusiasts who want to get the most out of their braking system.
FAQ: Häufige Fragen
Sollte ich die Anker- bzw. Staubbleche entfernen?
Wir empfehlen das Entfernen der Bleche, da sie die Belüftung einschränken. Ohne diese Barriere wird die Bremse effizienter gekühlt und bleibt auch bei starker Beanspruchung leistungsfähig.
Wie erleichtere ich mir die Felgenmontage?
Mit Radmontagehilfen gelingt das Ausrichten und Aufsetzen der Felge einfacher und präziser. Das schützt Gewinde und Felge und spart Zeit.
Radmontagehilfe ansehen
Benötige ich Spurverbreiterungen nach dem Umbau?
Welche Felgengröße passt, lässt sich pauschal nicht sagen. Streift die Felge minimal am Bremssattel, schaffen Spurverbreiterungen den nötigen Abstand.
Spurverbreiterungen ansehen
Brauche ich neue Bremsleitungen?
Für optimale Passform und stabile Bremswirkung empfehlen wir Stahlflex. Diese sind konfigurierbar und liefern konstantere Ergebnisse als Gummileitungen.
Stahlflex konfigurieren
Warum unsere Adapter die beste Wahl sind
Wusstest du, dass sich dein EPYTEC-Adapter oft schon nach dem ersten Verschleißteilwechsel komplett bezahlt macht?
Das liegt daran, dass du mit unseren Adaptern auf OE-Bremsscheiben und -Sättel setzt, die wir bewusst bei der Entwicklung der Adapter ausgewählt haben. Diese Komponenten sind nicht nur in höchster Qualität gefertigt und in Serienfahrzeugen im Einsatz, sondern durch ihre Großserienproduktion auch günstig und jederzeit verfügbar.
Für dich bedeutet das: erstklassige Bremsleistung ohne Abhängigkeit von teuren Speziallösungen anderer Hersteller.
Und selbst beim TÜV hast du es leichter, denn unsere OE-Komponenten sind bereits offiziell abgenommen – der Prüfer kann sich direkt darauf beziehen, sodass deine Eintragung unkompliziert und sicher abläuft.
Please note that our articles have been designed for racing and motorsport. Use in public road traffic usually requires an individual approval in accordance with § 21 StVZO by an officially recognised expert. Further information can be found under TÜV Süd. For the individual approval, we will provide you with an expert opinion or material certificate, if available.
Brake caliper hole spacing:
256
Hole spacing steering knuckle:
138
Manufacturer:
Epytec
Mounting location:
front
Brake caliper hole spacing:
256
Hole spacing steering knuckle:
138
Manufacturer:
Epytec
Mounting location:
front
Login
or Register with...
- Can I also use other brake discs as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information: https://epytec.de/uk/custom-made-products/brake-technology/adapters-for-brake-systems
- Can I also use other brake calipers as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information:
| Motor | Motorcode |
|---|---|
| John Cooper Works | F54|231PS(170KW) |
| Cooper S ALL4 | F54|178PS(131KW) |
| Cooper | F54|136PS(100KW) |
| Cooper S | F54|192PS(141KW) |
| John Cooper Works | F54|306PS(225KW) |
| Cooper SD | F54|163PS(120KW) |
| Cooper S JCW | F54|211PS(155KW) |
| One | F54|102PS(75KW) |
| Cooper S JCW ALL4 | F54|211PS(155KW) |
| One D | F54|116PS(85KW) |
| Cooper D | F54|150PS(110KW) |
| Cooper S ALL4 | F54|192PS(141KW) |
| Cooper SD ALL4 | F54|190PS(140KW) |
| Cooper S | F54|178PS(131KW) |
| Cooper SD ALL4 | F54|163PS(120KW) |
| Cooper SD | F54|190PS(140KW) |
| Cooper S ALL4 | F54|163PS(120KW) |
| Cooper S | F54|163PS(120KW) |
| Cooper D | F54|136PS(100KW) |
| Motor | Motorcode |
|---|---|
| 220d xDrive | F46|163PS(120KW) |
| 220d | F46|190PS(140KW) |
| 214d | F46|95PS(70KW) |
| 218d | F46|136PS(100KW) |
| 220d xDrive | F46|190PS(140KW) |
| 220d | F46|163PS(120KW) |
| 218d | F46|150PS(110KW) |
| 218d xDrive | F46|150PS(110KW) |
| 220i | F46|178PS(131KW) |
| 216d | F46|116PS(85KW) |
| 216i | F46|102PS(75KW) |
| 218i | F46|140PS(103KW) |
| 220i | F46|192PS(141KW) |
| 216i | F46|109PS(80KW) |
| 218d xDrive | F46|136PS(100KW) |
| 218i | F46|136PS(100KW) |
| Motor | Motorcode |
|---|---|
| 218i | F45|136PS(100KW) |
| 220d xDrive | F45|163PS(120KW) |
| 225xe Plug-in-Hybrid | F45|136PS(100KW) |
| 220d | F45|190PS(140KW) |
| 220i | F45|192PS(141KW) |
| 225xe Plug-in-Hybrid | F45|220PS(162KW) |
| 214d | F45|95PS(70KW) |
| 216i | F45|102PS(75KW) |
| 216i | F45|109PS(80KW) |
| 220d xDrive | F45|190PS(140KW) |
| 216d | F45|116PS(85KW) |
| 218d | F45|136PS(100KW) |
| 218d | F45|150PS(110KW) |
| 218d xDrive | F45|150PS(110KW) |
| 220d | F45|163PS(120KW) |
| 218i | F45|140PS(103KW) |
| 220i | F45|178PS(131KW) |
| 225i | F45|231PS(170KW) |
| 218d xDrive | F45|136PS(100KW) |
| 225i xDrive | F45|231PS(170KW) |
| 220i | F45|163PS(120KW) |
| Motor | Motorcode |
|---|---|
| 218d | F23|136PS(100KW) |
| 218d | F23|150PS(110KW) |
| 220i | F23|184PS(135KW) |
| M 235i | F23|326PS(240KW) |
| 230i | F23|252PS(185KW) |
| 220d | F23|205PS(151KW) |
| M 240i | F23|340PS(250KW) |
| 218i | F23|136PS(100KW) |
| 220d | F23|190PS(140KW) |
| 225d | F23|224PS(165KW) |
| M 235i xDrive | F23|326PS(240KW) |
| 220d | F23|163PS(120KW) |
| 228i | F23|245PS(180KW) |
| M 240i xDrive | F23|340PS(250KW) |
| Motor | Motorcode |
|---|---|
| xDrive18d | F48|136PS(100KW) |
| xDrive25d | F48|231PS(170KW) |
| sDrive20i | F48|192PS(141KW) |
| xDrive25i | F48|231PS(170KW) |
| xDrive18d | F48|150PS(110KW) |
| sDrive20d | F48|163PS(120KW) |
| sDrive18i | F48|136PS(100KW) |
| xDrive20d | F48|163PS(120KW) |
| xDrive20i | F48|178PS(131KW) |
| sDrive16d | F48|116PS(85KW) |
| xDrive25e Plug-in-Hybrid | F48|220PS(162KW) |
| sDrive20d | F48|190PS(140KW) |
| sDrive20i | F48|178PS(131KW) |
| sDrive18d | F48|136PS(100KW) |
| xDrive20i | F48|192PS(141KW) |
| sDrive18i | F48|140PS(103KW) |
| sDrive18d | F48|150PS(110KW) |
| xDrive20d | F48|190PS(140KW) |
| Motor | Motorcode |
|---|---|
| xDrive25e Plug-in-Hybrid | F39|220PS(162KW) |
| sDrive20i | F39|192PS(141KW) |
| xDrive20d | F39|190PS(140KW) |
| xDrive20i | F39|178PS(131KW) |
| sDrive20i | F39|178PS(131KW) |
| xDrive18d | F39|150PS(110KW) |
| sDrive16d | F39|116PS(85KW) |
| sDrive20d | F39|190PS(140KW) |
| sDrive20d | F39|163PS(120KW) |
| xDrive18d | F39|136PS(100KW) |
| sDrive18i | F39|136PS(100KW) |
| sDrive18d | F39|136PS(100KW) |
| sDrive18i | F39|140PS(103KW) |
| xDrive20i | F39|192PS(141KW) |
| xDrive25d | F39|231PS(170KW) |
| M35i | F39|306PS(225KW) |
| xDrive20d | F39|163PS(120KW) |
| sDrive18d | F39|150PS(110KW) |
