Brake Caliper Adapter Golf MK4 Audi A3 TT Seat Leon 365x34 Brake Disc ZR18 Cayenne Porsche Brake Caliper
- ✓ 365X34 420615301D Audi RS4 B7 brake disc
- ✓ 6-piston 95535142153 / 95535142253 Porsche Cayenne ZR18 ZL18 brake caliper
- ✓ front axle
€173.75*
- Easy TÜV registration
- Quality Made in Germany
- Fair prices without middlemen you buy directly from the manufacturer and developer of the product
- Worldwide no. 1 in tuning adapters
- 15 years expert knowledge
- 10 years warranty
Brake caliper adapter on model Golf MK4 series, for conversion to Cayenne ZR18 brake caliper, combined with the 2-piece brake disc 365x34mm.
Suitable for following vehicles:
- Audi A3 (8L)
- Audi TT (8N)
- VW Golf MK4
- VW Bora
- VW Beetle
- VW Polo (9N)
- Seat Ibiza
- Seat Leon
- VW Polo 6r (WRC)
Since the 2-piece brake discs are made with their own pot, no spacer between the wheel hub and brake disc are necessary. Thus, your track does not get wider.
Important!:
The adapter is only suitable for cast wishbones OE: 8N0 407 151 A.
These are installed as standard in the Golf 4 R32, Audi S3 8L, and Audi TT 8N 1.8T and the Quattro models. All other models of the Golf 4, Audi A3 series must be converted to this cast wishbone, otherwise no more steering is possible. The stabilizer OE: 1J0411305AF must also be converted in vehicles that do not have the cast wishbone installed as standard.
We have the right wishbones in the matching accessories and can be ordered directly.
The problem with the wishbone only affects conversions to Z18 and Z17 calipers. With all other adapters that we still have, such as conversion to 4-piston Porsche Boxter, Audi TTRS or 6-piston Porsche Panamera brake calipers for the Golf 4 Audi A3 series, the adapters fit with all wishbones.
Advantages of this brake system:
- high deceleration, also in conjunction with our rear axle braking system
- thanks to the material certificate supplied with the order, it is possible to register your purchase even for series vehicles
- directly fit to the above-mentioned models and therefore can always be restored to the original state without any problems
- our EPYTEC brake caliper adapters do not require any sending of your serial parts, no welding, milling or drilling
Required components:
- brake caliper: Porsche Cayenne ZR18 ZL18, reference 95535142153 / 95535142253
- brake disc: 2-piece 365x34 mm with PCD 5x100 and 5x112. EPYTEC item number:948
- adapter only suitable with original support joints
- brake pads must be adapted at the top edge to prevent them from overhanging
Delivery:
- 2x brake caliper adapters
- 2x centering rings
- high-strength screws
- Template to check whether the brake system fits under your rim
- material certificate
Tips, information and notes:
- For better ventilation of the brake system, we recommend removing the anchor plates/brake dust plates.
- Install the adapter with the required components and then check whether new brake lines are required, as the old ones may not be long enough or the connection may not fit, depending on the model. Due to the significantly better efficiency, we recommend switching to steel braided lines. We have developed a steel braided line configurator especially for this function, where you can assemble and then install them according to your requirements.click here for the steel braided line configurator >>configure steel braided brake line<<
Please note that our articles have been designed for racing and motorsport. Use in public road traffic usually requires an individual approval in accordance with § 21 StVZO by an officially recognised expert. Further information can be found under TÜV Süd. For the individual approval, we will provide you with an expert opinion or material certificate, if available.
Technical data:
Login
13 June 2023 21:21
maxtuner123
Very good quality product !!
27 April 2021 08:46
ALEXANDRE B
super produit comme toujours , très bonne qualité je recommande !
- Can I also use other brake discs as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information: https://epytec.de/uk/custom-made-products/brake-technology/adapters-for-brake-systems
- Can I also use other brake calipers as specified in the required components?
No, unfortunately that is not possible. The reason is simply: all brake calipers have different heights and depths. If another brake disc is installed, the brake caliper would either not fit on the adapter or not run in the middle of the brake disc. But if you want to install a different brake caliper, we also have an option for you. You can have a custom-made product made for you, take a look at the following link for more information:
